NVC-HM

NVC-HM

· Application

- A vertical lifting clamp for steel plates and steel blocks with large bevel angle.

- An efficient clamp for special operation. The NVC-HM makes it easy to lift long V- or X-shaped beveled work pieces.



· Features

- A special lightweight bevel clamp with a safety factor of 3. The bottom(“D1” and “D2” in the drawing) of the clamp is

  long and it consists of two swivel jaws.

- The NVC-HM has the built-in safety latch that prevents a work piece from slipping due to the initial clamping force

  caused by the spring even if the wire rope becomes loose during the operation.



· How to use

- Insert the beveled area of a work piece into the inside end of the jaw opening and then lock the safety latch.

- Clamp the center of gravity of the work piece in order to equally distribute the weight of the work piece.



· Warnings

- Do not exceed the rated capacity specified on the clamp because the NVC-HM is a lightweight clamp with a safety

  factor of 3.

- Lift a work piece only which falls within the jaw opening range specified in the instruction manual.

- Do not lift a work piece whose beveled area sticks out of the cam and the jaw(“D1”).

- Never lift two or more work pieces with one clamp.

- Lift a work piece only after checking the biting location and the biting condition of the work piece, and the proper

  functioning of the safety latch.
