Products

· Application

- A no teeth mark horizontal clamp that leaves no teeth mark on work pieces after clamping. This model is used to lift

  materials (angles) for building a variety of tanks that store or transport chemical products.

· Features

- The NGC-HF has the built-in safety latch that prevents a work piece from slipping due to the initial clamping force

  caused by the spring even if the wire rope becomes loose during the operation.

· How to use

- Insert a work piece into the inside end of the clamp's jaw opening and then lock the safety latch.

- Clamp the center of gravity of a work piece in order to equally distribute the weight of the work piece.

· Warnings

- Before clamping, remove oil or grease on a work piece with detergent and a cloth to prevent slipping.

- The cam and the swivel jaw of no teeth mark clamps get easily worn out. Therefore, always check the wear and tear of

  clamp components before lifting.

- Do not vertically lift with horizontal clamps.

- Do not exceed the rated capacity specified on the clamp.

- Lift a work piece only which falls within the jaw opening range specified in the instruction manual.

- Never lift two or more work pieces with one clamp.

- Lift a work piece only after checking the biting location and the biting condition of the work piece, and the proper

  functioning of the safety latch.

- When lifting a work piece, a signal man must be outside the rotation radius of a work piece to send a signal to a crane

  operator.
