NVC-HS

· Application

- A vertical lifting clamp for carrying massive amounts of steel plates and steel blocks in small space.

· Features

- A special carrying clamp whose bottom (“B” in the drawing) is designed to be low in order to use low wooden loading

  blocks (wooden support blocks).

- The NVC-HS has the built-in safety latch that prevents a work piece from slipping due to the initial clamping force

  caused by the spring even if the wire rope becomes loose during the operation.

· How to use

- Insert a steel plate into the inside end of the clamp's jaw opening and then lock the safety latch.

- Clamp the center of gravity of a work piece in order to equally distribute the weight of the work piece.

Warnings

- Do not exceed the rated capacity specified on the clamp since the NVC-HS is designed to be lightweight with a safety

  factor of 3.

- Use a work piece only which falls within the jaw opening range specified in the instruction manual.

- Never lift two or more work pieces with one clamp.

- Lift a work piece only after checking the biting location and the biting condition of the work piece, and the proper

  functioning of the safety latch.

- When lifting a work piece, a signal man must be outside the rotation radius of a work piece to send a signal to a crane

  operator.
